iSpeech API Specification Version 2.2

iSpeech Text to Speech and Speech Recognition API Specification

This document provides a detailed description of the iSpeech API and examples for almost every possible use case. It demonstrates how to dynamically retrieve API key properties such as voice lists, credits, and enabled key options. Wireshark and RESTClient are recommended for viewing network transactions, creating requests, and debugging code.


Last Updated: May 23, 2013.



Application Programming Interface (API)

Developer Guide

iSpeech Inc. (“iSpeech”) has made efforts to ensure the accuracy and

completeness of the information in this document. However, iSpeech Inc. disclaims all

representations, warranties and conditions, whether express or implied, arising by

statute, operation of law, usage of trade, course of dealing or otherwise, with respect to

the information contained herein. iSpeech Inc. assumes no liability to any party for any

loss or damage, whether direct, indirect, incidental, consequential, special or exemplary,

with respect to (a) the information; and/or (b) the evaluation, application or use of any

product or service described herein.

iSpeech Inc. disclaims any and all representation that its products or services infringe

upon any existing or future intellectual property rights. iSpeech Inc. owns and retains all

right, title and interest in and to the iSpeech Inc. intellectual property, including without

limitation, its patents, marks, copyrights and technology associated with the

iSpeech Inc. services. No title or ownership of any of the foregoing is granted or

otherwise transferred hereunder. iSpeech Inc. reserves the right to make changes to

any information herein without further notice.

Revision History

PUBLISH DATE

UPDATES

Aug  8, 2011

Document created

Sept 13, 2011

Added ASR

Sept 21, 2011

Added AMR to ASR

Nov 9, 2011

Added voice command examples

Nov 10, 2011

Removed references to ASR Raw POST

Nov 11, 2011

Made output variable explicit for ASR and voice list examples

Nov 17, 2011

Specified HTTP POST/GET instead of REST, fixed /r/n typos

Nov 22, 2011

Added reference for Speex in ASR content-type example

Dec 12, 2011

Added endpadding and startpadding variables

Dec 12, 2011

Added TTS examples, added background highlighting to emphasize examples

Aug 24, 2012

Added position markers and visemes

Aug 24, 2012

Added Flash, Javascript/Flash, Ruby, Python, Perl SDKs

Aug 24, 2012

Added link to automated payment system

Aug 24, 2012

Added pitch parameter to TTS

Aug 30, 2012

Added standard non-freeform speech recognition models

Aug 30, 2012

Added speech recognition speex modes

Sept 10, 2012

Added bit depth

Sept 10, 2012

Added TTS file formats: alaw, ulaw, vox, and mp4

Sept 10, 2012

Added errors

Sept 10, 2012

Changed ASR language to locale

Oct 3, 2012

Add filename parameter to TTS

Nov 12, 2012

Removed eurdutchmale voice

Jan 22, 2013

Added Math Markup Language (MathML) information and examples

Jan 24, 2013

Added Speech Synthesis Markup Language (SSML) information and examples

Mar 4, 2013

Corrected content-length for JSON TTS example

Mar 13, 2013

Updated ASR locale list, added Web ASR freeform mode.

Table of Contents

Revision History

Section 1 Introduction



   Minimum Requirements

      Internet Connection

      HTTP Protocol

      API Key

   Managing API Key Settings

      View/Edit Keys

   API Features

      Information

      Text to Speech

      Automated Speech Recognition

      Position Markers

      Visemes

   API Key Information Retrieval

   Developer Support

      Sales

      Support/Troubleshooting

   Software Development Kits

       Availability

       API Access Pricing

Section 2 Text to Speech

   Transaction Types and URL Formats

      HTTP GET/POST: URL Encoded, XML, JSON

   Request Parameters

   Voices

   Voice List Retrieval
     HTTP GET: URL Encoded, XML, JSON

   Speed

   Formats

   Bitrates

   Padding

   Pitch

   Bit Depth

   Filename

   Speech Synthesis Markup Language (SSML) tags

   Math Markup Language (MathML) tags

   Example Transactions

      Summary

      HTTP POST: URL Encoded → Binary Audio

      HTTP POST: JSON → Binary Audio
     HTTP POST: XML → Binary Audio

      HTTP GET: URL Encoded → URL Encoded (this transaction purposely contains an error)

      Math Markup Language HTTP GET/POST: URL Encoded, JSON, XML → Binary Audio

   Error Codes for Text-to-Speech and General Errors

Section 3 Automated Speech Recognition



   Transaction Types and URL Formats

      HTTP GET/POST: URL Encoded, XML, JSON

   Request Parameters

   Locales

      Standard Locales

      Custom Locales

   Speech Recognition Models

      Standard freeform models

      Standard non-freeform models

      Custom

   Speex Modes

   Example Transactions for Freeform Speech

      Format of Examples

      HTTP POST: URL Encoded → URL Encoded

      HTTP POST: JSON → JSON

      HTTP POST: XML → XML

   Command Lists

      About

      Example Transactions for Command Lists

         Formatting of Examples

         HTTP POST: XML → XML

         HTTP POST: URL Encoded → URL Encoded

         HTTP POST: JSON → JSON

         HTTP POST: XML → XML -- Detecting multiple audio commands from multiple command lists

   Error Codes for Speech Recognition and General Errors


Section 4 Position Markers



   Transaction Types and URL Formats

      HTTP GET/POST: URL Encoded, XML, JSON

   Request Parameters

   Introduction

   Example Transaction

      HTTP GET: URL Encoded → XML

   Marker Information Usage Technique

       Media Player Considerations

       Implementation

   Error Codes for Position Markers and General Errors

Section 5 Visemes



   Transaction Types and URL Formats

      HTTP GET/POST: URL Encoded, XML, JSON

   Request Parameters

   Introduction

   Example Transaction

      HTTP GET: URL Encoded → XML

   Viseme Chart

   Viseme Usage Technique

       Media Player Considerations

       Implementation

   Error Codes for Visemes and General Errors

Section 1

Introduction

Welcome to the iSpeech Inc. Application Programming Interface (API) Developer Guide.  This guide describes the available variables, commands, and interfaces that make up the iSpeech API.

The iSpeech API allows developers to implement Text-To-Speech (TTS) and Automated Voice Recognition (ASR) in any Internet-enabled application.

The API's are platform agnostic which means any device that can record or play audio that is connected to the Internet can use the iSpeech API.

Minimum Requirements

Below are the minimum requirements needed to use the iSpeech API.  The API can be use with and without a software development kit (SDK).

Internet Connection

iSpeech services require an Internet connection.

HTTP Protocol

The iSpeech API follows the HTTP standard by using GET and POST.  Some web browsers limit the length of GET requests to a few thousand characters.

Request/Responses

Requests can be in URL-encoded, JSON, or XML data formats.  You can specify the output data format of responses.  For TTS, binary data is usually returned if the request is successful.  For speech recognition, URL-encoded text, JSON, or XML can be returned by setting the output variable.

API Key

An API key is a password that is required for access.  To obtain an API key please visit: http://www.ispeech.org/developers and register for a developer account.

Managing API Key Settings

View/Edit Keys

Manage your API keys by using the iSpeech developer website: http://www.ispeech.org/developers.  You can request additional features for your API keys on that website.

API Features

Information

You can retrieve the properties of your API keys.  Key information includes a voice list, amount of credits, locales, and many other parameters.

Text to Speech

You can synthesize spoken audio through iSpeech TTS in a variety of voices, formats, bitrates, frequencies, and playback speeds.  Math markup language (MathML) and Speech synthesis markup language (SSML) are also supported.

Automated Speech Recognition

You can convert spoken audio to text using a variety of languages and recognition models.  We can create custom recognition models to improve recognition quality.

Position Markers

You can get the position in time when words are spoken in TTS audio.

Visemes

You can get the position in time of mouth positions when words are spoken in TTS audio.

API Key Information Retrieval

Replace “developerdemokeydeveloperdemokey” with your API key.

HTTP GET Request and Response

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&action=information&output=rest

[…]&voice-locale-94-1=ja&voice-locale-94-2=ja-jp&voice-gender-94=female
&voice-description-94=Japanese+Female+Voice&
wordlimit=40&model=assistant%2cdate
%2cnfl%2cnba%2cusmoney%2cmlb%2cnumbersto9%2cnumbersto99%2cnumbersto999%2ctime
%2cphonenumber%2cstreets%2csportsteam%2ccitystate&
credits=5672606&unlimited=enabled
&alias=enabled&asr-sms=enabled&asr-voicemail=enabled&asr-dictation=enabled

Developer Support

Sales



Automated purchasing system: https://www.ispeech.org/developer/purchase/

iSpeech sales can be contacted at the following phone number: +1-917-338-7723 from 10 AM to 6 PM Eastern Time, Monday to Friday.  You can also email sales@ispeech.org.

Support / Troubleshooting

Please look for the answer to your problem in the iSpeech Developer Forum: http://www.ispeech.org/forums/

Software Development Kits

iSpeech SDKs simplify the iSpeech API.  You should use iSpeech SDKs if the option is available.  Only mobile SDKs made by iSpeech allow you to use the iSpeech API for free.

Availability

iPhone, Android, BlackBerry, .NET, Java (Server), PHP, Flash, Javascript/Flash, Ruby, Python, Perl

API Access Pricing

PLATFORMS

PRICE

iPhone, Android, BlackBerry

Free with fair usage using iSpeech SDK for non-revenue generating apps.  Apps must follow the iSpeech standard usage guidelines for branding.

.NET, Java, PHP, Flash, Ruby, Python, Perl

Between $0.05 and $0.0001 per word (TTS) or transaction (ASR), depending on quantity

Section 2

Text to Speech

The iSpeech Text-To-Speech API allows you to synthesize high-quality spoken audio in multiple formats. The iSpeech API doesn’t use callbacks because it’s fast and synchronous. You'll always receive audio data or an error message in the same HTTP transaction.

Transaction Types and URL Formats

TRANSACTION TYPE

INPUT FORMAT

URL

HTTP GET/POST

URL Encoded

http://api.ispeech.org/api/rest

HTTP GET/POST

XML

http://api.ispeech.org/api/xml

HTTP GET/POST

JSON

http://api.ispeech.org/api/json

Request Parameters

PARAMETER

DATA TYPE

EXAMPLE VALUE

Apikey

32 character hex integer

abcdef1234567890abcdef1234567890

Action

String

convert, ssml

Text

String

Hello World

Ssml (optional)

String

<?xml version=”1.0” ?><speak version= […]

Voice (optional)

String

usenglishfemale (default)

Format (optional)

String

mp3 (default)

Frequency (optional)

Integer (hertz)

16000 (default)

Bitrate (optional)

Integer (kbps)

48 (default)

Speed (optional)

Integer

-10 to 10 (default: 0)

Startpadding (optional)

Integer (seconds)

5 (default: 0)

Endpadding (optional)

Integer (seconds)

5 (default: 0)

Pitch (optional)

Integer

0 to 200 (default: 100)

Bitdepth (optional)

Integer (bits per sample)

8 or 16 (default: 16)

Filename (optional)

String

myaudio or myaudio.mp3 (default: rest.*)

Library (optional)

String

libmath

Example HTTP GET Request (Using most variables)

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&action=convert&text=something&voice=usenglishfemale&format=mp3
&frequency=44100&bitrate=128&speed=1&startpadding=1&endpadding=1
&pitch=110&filename=myaudiofile

Voices

Standard Voices

Name

Alias

US English Female (default)

usenglishfemale

US English Male

usenglishmale

UK English Female

ukenglishfemale

UK English Male

ukenglishmale

Australian English Female

auenglishfemale

US Spanish Female

usspanishfemale

US Spanish Male

usspanishmale

Chinese Female

chchinesefemale

Chinese Male

chchinesemale

Hong Kong Cantonese Female

hkchinesefemale

Taiwan Chinese Female

twchinesefemale

Japanese Female

jpjapanesefemale

Japanese Male

jpjapanesemale

Korean Female

krkoreanfemale

Korean Male

krkoreanmale

Canadian English Female

caenglishfemale

Hungarian Female

huhungarianfemale

Brazilian Portuguese Female

brportuguesefemale

European Portuguese Female

eurportuguesefemale

European Portuguese Male

eurportuguesemale

European Spanish Female

eurspanishfemale

European Spanish Male

eurspanishmale

European Catalan Female

eurcatalanfemale

European Czech Female

eurczechfemale

European Danish Female

eurdanishfemale

European Finnish Female

eurfinnishfemale

European French Female

eurfrenchfemale

European French Male

eurfrenchmale

European Norwegian Female

eurnorwegianfemale

European Dutch Female

eurdutchfemale

European Polish Female

eurpolishfemale

European Italian Female

euritalianfemale

European Italian Male

euritalianmale

European Turkish Female

eurturkishfemale

European Turkish Male

eurturkishmale

European German Female

eurgermanfemale

European German Male

eurgermanmale

Russian Female

rurussianfemale

Russian Male

rurussianmale

Swedish Female

swswedishfemale

Canadian French Female

cafrenchfemale

Canadian French Male

cafrenchmale

HTTP GET Request (Setting voice to European French Female)

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&action=convert&text=something&format=mp3&
voice=eurfrenchfemale

Custom Voices

Custom Voices may be enabled for your account.  They can be found in the developer portal -> api key properties -> custom voices.  You can use them by setting the variable voice to the custom alias.

Name

Alias

President Obama

Obama (voice=obama)

Custom Voice

customvoice1 (voice=customvoice1)

Voice List Retrieval

A current list of voices that are enabled for an API key can be retrieved in REST, JSON, and XML format by using the following service.  HTTP GET and POST are supported.  A web browser or a REST client can be used to make these HTTP requests.

HTTP GET Network Transaction to get XML voice list.

HTTP GET Request and XML Response

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey

&action=information&output=xml

<?xml version='1.0'?>

<data>

    <result>success</result>

    <voice-1>krkoreanfemale</voice-1>

    <voice-locale-1-1>ko-kr</voice-locale-1-1>

    <voice-locale-1-2>ko</voice-locale-1-2>

    <voice-gender-1>female</voice-gender-1>

    <voice-description-1>Korean Female Voice</voice-description-1>

    <voice-2>usenglishfemale</voice-2>

    <voice-locale-2-1>en-us</voice-locale-2-1>

    <voice-locale-2-2>en</voice-locale-2-2>

    <voice-gender-2>female</voice-gender-2>

    <voice-description-2>United States English Female Voice</voice-description-2>

    [... more voices ...]

</data>



HTTP GET Network Transaction to get JSON voice list.

HTTP GET URL Encoded Request and JSON Response

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&
action=information&output=json

{"voice-gender-48":"female","voice-locale-22-1":"fr-ca","voice-locale-8-1":"pt-br","voice-description-2":"Finnish Female Voice","voice-description-3":"Hong Kong Chinese Male Voice","voice-58":"eurdanishfemale","voice-description-1":"Korean Female Voice","voice-description-6":"Chinese Female Voice","voice-description-7":"United Kingdom English Female Voice","voice-description-4”, [...more voices...]}

HTTP GET Network Transaction to get URL Encoded voice list.

HTTP GET URL Encoded Request and URL Encoded Response

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&
action=information&output=rest

result=success&voice-1=krkoreanfemale2&voice-locale-1-1=ko-kr&voice-gender-1=female&voice-description-1=Korean+Female+Voice&voice-2=eurfinnishfemale&voice-locale-2-1=fi-fi&voice-gender-2=female&voice-description-2=Finnish+Female+Voice&voice-3=chchinesemale1&voice-locale-3-1=zh&voice-locale-3-2=zh-hk[...more voices...]

Speed

Most voices support speed controls.

Speed

Value (integer)

Fastest

10

Faster

Speed > 0

Normal (default)

0

Slower

Speed < 0

Slowest

-10

HTTP GET Request (Setting speed to 5)

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&action=convert&text=something&voice=usenglishfemale&format=mp3&
speed=5


Bitrates

Note: Bitrates can only be selected for MP3s.

Valid values are 16, 24, 32, 48 (default), 56, 64, 80, 96, 112, 128, 144, 160, 192, 224, 256, or 320.

Bitrates are listed in kilobits per second.

HTTP GET Request (Setting bitrate to 16 kilobits per second)

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&action=convert&text=something&voice=usenglishfemale&format=mp3&
bitrate=16

Formats

Name

File extension

Audio Interchange File Format

aiff

MPEG Layer 3 (default)

mp3

Ogg Vorbis

ogg

Windows Media Audio

wma

Free Lossless Audio Codec

flac

Wave PCM

wav

Wave (alaw)

alaw

Wave (µ-law)

ulaw

Dialogic ADPCM

vox

MPEG-4

mp4

Example HTTP GET Request (Setting format to wav)

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&action=convert&text=something&voice=usenglishfemale&
format=wav

Frequencies

Possible values: 8000, 11025, 16000 (default), 22050, 24000, 32000, 44100, 48000 cycles per second (Hertz)

Example HTTP GET Request (Setting frequency to 16000 Hz)

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&action=convert&text=something&voice=usenglishfemale&
frequency=16000

Padding

Padding adds silence to a section of the audio file.

Start Padding

Adds a period of silence to the beginning of the audio file.

Example HTTP GET Request (Setting start padding to 3 seconds)

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&action=convert&text=something&voice=usenglishfemale&
startpadding=3

End Padding

Adds a period of silence to the beginning of the audio file.

Example HTTP GET Request (Setting end padding to 3 seconds)

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&action=convert&text=something&voice=usenglishfemale&
endpadding=3

Pitch


Possible values: 0 to 200 (integer), 0 is lowest pitch, 100 is default, 200 is highest pitch. Pitch is enabled only on some voices.

Example HTTP GET Request (Setting pitch to 50)

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&action=convert&text=something&voice=usenglishfemale&
pitch=50

Bit Depth

The bit depth is amount of audio detail for each audio sample.

Possible values are 8 and 16 (default) bits/sample on AIFF, FLAC, and WAVE file formats.

Example HTTP GET Request (Setting bit depth to 8)

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&action=convert&text=something&voice=usenglishfemale&format=wav
&
bitdepth=8


Filename

The filename is the name of the audio file that will download.  Specifying the extension is optional.  If the extension is missing, the correct extension will be added automatically.  The default is rest.[extension], for example:  rest.mp3.

Example HTTP GET Request (Setting filename of audio)

http://api.ispeech.org/api/rest?apikey=developerdemokeydeveloperdemokey
&action=convert&text=something&voice=usenglishfemale&format=wav
&
filename=myaudiofile

Speech Synthesis Markup Language (SSML)

SSML tags are used to customize the way a text-to-speech engine creates audio.  The tags can be used to add pauses, change emphasis, and change pronunciation.  This option is disabled by default but can be requested by emailing sales@ispeech.org.

The parameter “action” must set to “ssml” and the parameter “ssml” must be set to a complete SSML XML statement.  The parameter “text” is not used and the parameters voice and speed should be represented using the “voice” and “prosody” SSML tags instead of request parameters.

Example HTTP GET Request (Emphasis added on the word big)

http://api.ispeech.org/api/rest?apikey=YOUR_API_KEY_HERE&

action=ssml&ssml=%3C%3Fxml%20version%3D%221.0%22%3F%3E%3Cspeak

%20version%3D%221.0%22%20xmlns%3D%22http%3A%2F%2Fwww.w3.org

%2F2001%2F10%2Fsynthesis%22%20xmlns%3Axsi%3D%22http%3A%2F%2F

www.w3.org%2F2001%2FXMLSchema-instance%22

%20xsi%3AschemaLocation%3D%22http%3A%2F%2Fwww.w3.org%2F2001

%2F10%2Fsynthesis%20http%3A%2F%2Fwww.w3.org%2FTR%2Fspeech-synthesis

%2Fsynthesis.xsd%22%20xml%3Alang%3D%22en-US%22%3E

That%20is%20a%20%3Cemphasis%3E%20big%20%3C%2Femphasis%3E%20car!

%3C%2Fspeak%3E

SSML used:

<?xml version="1.0"?>

<speak version="1.0" xmlns="http://www.w3.org/2001/10/synthesis"

         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"

         xsi:schemaLocation="http://www.w3.org/2001/10/synthesis

                   http://www.w3.org/TR/speech-synthesis/synthesis.xsd"

         xml:lang="en-US">

  That is a <emphasis> big </emphasis> car!

</speak>

Audio synthesized as, “That is a BIG car!”.

More information on SSML can be found at: http://www.w3.org/TR/speech-synthesis/.

Math Markup Language (MathML)

MathML tags are used to display and represent mathematical statements.  This option is disabled by default but can be requested by emailing sales@ispeech.org.

Remember to set “library” to “libmath” so that the MathML processor loads your text as MathML.

Example HTTP GET Request (Setting library to libmath)

http://api.ispeech.org/api/rest?action=convert

&apikey=YOUR_API_KEY_HERE&library=libmath

&text=%3Cfmath%3E%3Cmrow%3E%3Cmtext%3E%3Csup%3E%2B%3C%2Fsup%3E%3C%2Fmtext%3E

%3Cmn%3E7%3C%2Fmn%3E%3C%2Fmrow%3E%3C%2Ffmath%3E

MathML used: <mrow><mtext><sup>+</sup></mtext><mn>7</mn></mrow>

Audio synthesized as, “positive 7” instead of plus 7.

More information on MathML can be found at: https://developer.mozilla.org/en-US/docs/MathML

The following table lists MathML tags supported by the iSpeech API.

MathML Tag

Purpose

mfrac

Used to display fractions

mi

Rendered as an identifier such as function names, variables or symbolic constants.

mn

A numeric literal which is normally a sequence of digits with a possible separator (a dot or a comma). However, it is also allowed to have arbitrary text in it which is actually a numeric quantity, for example "eleven".

mo

An operator in a broad sense. Besides operators in strict mathematical meaning, this element also includes "operators" like parentheses, separators like comma and semicolon, or "absolute value" bars.

mroot

Displays roots with an explicit index. Two arguments are accepted, which leads to the syntax:<mroot> base index </mroot>.

mrow

Groups sub-expressions, which usually contain one or more operators with their respective operands (such as <mi> and <mn>). This element renders as a horizontal row containing its arguments.

msqrt

Displays square roots (no index is displayed). The square root accepts only one argument, which leads to the following syntax: <msqrt> base </msqrt>.

msup, sup

Attaches a superscript to an expression.

mtext

Renders arbitrary text with no notational meaning, such as comments or annotations.

mspan, span

Used for highlighting text or just general styling of an equation

mtable, table

Creates tables or matrices. Inside a <mtable>, only <mtr> and <mtd> elements may appear. These elements are similar to <table>, <tr> and <td> elements of HTML.

Example Transactions

Summary

The following examples are packet captures from TCP connections that used the HTTP protocol.  You can compare your network traffic to these transactions to debug code.  Wireshark can be used to analyze network connections.  A REST client can be used to make these HTTP requests.

HTTP POST URL encoded request for Text to Speech

HTTP POST Request and Reply

POST /api/rest HTTP/1.1

Content-Length: 71

Content-Type: text/plain; charset=UTF-8

Host: api.ispeech.org

Connection: Keep-Alive

apikey=developerdemokeydeveloperdemokey&action=convert&text=hello+world

HTTP/1.0 200 OK

Connection: close

Server: iSpeech Cloud/1.2

Accept-Ranges: none

X-Time-Length: 3853

X-Content-Hash: e969ef3dd0dc0e9c417f31f7ffbd10ed

Content-Length: 23760

Content-Type: audio/mpeg

Cache-Control: no-cache, no-store, must-revalidate, max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

[mp3 binary audio data]

HTTP POST JSON request for Text to Speech

HTTP POST, JSON Request and Reply

POST /api/json HTTP/1.1

Content-Length: 111

Content-Type: application/json; charset=UTF-8

Host: api.ispeech.org

Connection: Keep-Alive

{"apikey":"developerdemokeydeveloperdemokey","action":"convert","text":"hello world","voice":"usenglishfemale"}

Connection: close

Server: iSpeech Cloud/1.2

Accept-Ranges: none

X-Time-Length: 3853

X-Content-Hash: e969ef3dd0dc0e9c417f31f7ffbd10ed

Content-Length: 23760

Content-Type: audio/mpeg

Cache-Control: no-cache, no-store, must-revalidate, max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

[mp3 audio binary data]



HTTP POST XML request for Text to Speech

HTTP POST, XML Request and Reply

POST /api/xml HTTP/1.1

Content-Length: 150

Content-Type: application/xml; charset=UTF-8

Host: api.ispeech.org

Connection: Keep-Alive

<data>

<apikey>developerdemokeydeveloperdemokey</apikey>

<action>convert</action>

<text>hello world</text>

<voice>usenglishfemale</voice>

</data>

HTTP/1.0 200 OK

Connection: close

Server: iSpeech Cloud/1.2

Accept-Ranges: none

X-Time-Length: 3853

X-Content-Hash: 4affe15913fccd851ebf08a7e2650955

Content-Length: 23760

Content-Type: audio/mpeg

Cache-Control: no-cache, no-store, must-revalidate, max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

[mp3 audio binary data]

Example of a text-to-speech network transaction with an error

Responses with an error message return HTTP status response code “HTTP/1.0 202 Accepted”.

HTTP GET, URL Encoded Request and Reply (Error: misspelled voice)

GET /api/rest?apikey=developerdemokeydeveloperdemokey&action=convert&

text=something&output=rest&voice=usenglishfemal HTTP/1.1

Host: api.ispeech.org

Connection: keep-alive

User-Agent: Mozilla/5.0 (Windows NT 6.1; WOW64) AppleWebKit/535.2 (KHTML, like Gecko) Chrome/15.0.874.58 Safari/535.2

Accept: text/html,application/xhtml+xml,application/xml;q=0.9,*/*;q=0.8

Accept-Encoding: gzip,deflate,sdch

Accept-Language: en-US,en;q=0.8

Accept-Charset: ISO-8859-1,utf-8;q=0.7,*;q=0.3

HTTP/1.0 202 Accepted

Server: iSpeech Cloud/1.2

Connection: close

Content-Length: 41

Content-Type: text/plain

Cache-Control: no-cache, no-store, must-revalidate, max-age=0,

proxy-revalidate, no-transform

Pragma: no-cache

result=error&code=8&message=Invalid+voice

Example network transactions containing MathML

Summary

The following examples are packet captures from TCP connections that used the HTTP protocol.  You can compare your network traffic to these transactions to debug code.  Wireshark can be used to analyze network connections.  A REST client can be used to make these HTTP requests.

More information on MathML is available on http://www.w3.org/TR/MathML2/ and https://developer.mozilla.org/en-US/docs/MathML

HTTP GET URL encoded Text-to-Speech request containing MathML

Request information

Text: “+7” (says, positive seven)

MathML used: <mrow><mtext><sup>+</sup></mtext><mn>7</mn></mrow>

HTTP GET, URL Encoded Request and Reply, +7 (says positive 7)

GET /api/rest?action=convert&voice=usenglishfemale

&apikey=YOUR_API_KEY_HERE&library=libmath&format=mp3

&text=%3Cfmath%3E%3Cmrow%3E%3Cmtext%3E%3Csup%3E%2B%3C%2Fsup%3E%3C%2Fmtext%3E

%3Cmn%3E7%3C%2Fmn%3E%3C%2Fmrow%3E%3C%2Ffmath%3E HTTP/1.1

Host: api.ispeech.org

Connection: keep-alive

Cache-Control: no-cache

Pragma: no-cache

Accept-Encoding: identity;q=1, *;q=0

Accept: */*

Accept-Language: en-US,en;q=0.8

Accept-Charset: ISO-8859-1,utf-8;q=0.7,*;q=0.3

HTTP/1.0 200 OK

Connection: close

Access-Control-Allow-Origin: *

Server: iSpeech Cloud/1.2

Accept-Ranges: none

X-Time-Length: 927

X-Content-Hash: 7d125717aa5ac91de5b2b9f2ad6de873

Content-Length: 6264

Content-Type: audio/mpeg

Cache-Control: no-cache, no-store, must-revalidate, max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

[...mp3 binary data...]

HTTP POST JSON Text-to-Speech request containing MathML

Request Information

Text: “-3/5” (says, negative three fifths)

MathML used:

<mrow>

   <mtext><sup>-</sup></mtext>

   <span mtagname="mfrac"><span class="fm-vert fm-frac">

      <table><tbody>

         <tr><td class="fm-num-frac fm-inline"><mn>3</mn></td></tr>

         <tr><td class="fm-den-frac fm-inline"><mn>5</mn></td></tr>

      </tbody></table>

   </span></span>

</mrow>

HTTP POST JSON Request and Reply, -3/5 (says negative three fifths)

POST /api/json HTTP/1.1

Content-Length: 381

Content-Type: text/plain; charset=UTF-8

Host: api.ispeech.org

Connection: Keep-Alive

Expect: 100-Continue

{"apikey":"YOUR_API_KEY_HERE",

"action":"convert",

"text":"<mrow><mtext><sup>-</sup></mtext><span mtagname=\"mfrac\">

<span class=\"fm-vert fm-frac\">

<table><tbody>

<tr><td class=\"fm-num-frac fm-inline\"><mn>3</mn></td></tr>

<tr><td class=\"fm-den-frac fm-inline\"><mn>5</mn></td></tr>

</tbody></table>

</span></span></mrow>",

"voice":"usenglishfemale",

"library":"libmath"}

HTTP/1.0 200 OK

Connection: close

Access-Control-Allow-Origin: *

Server: iSpeech Cloud/1.2

Accept-Ranges: none

X-Time-Length: 1438

X-Content-Hash: 01338a58a7006a20e2b83e5536b34d3a

Content-Length: 9288

Content-Type: audio/mpeg

Cache-Control: no-cache, no-store, must-revalidate, max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

[...mp3 binary data...]



HTTP POST XML Text-to-Speech request containing MathML

The text: “+7” gets spoken as “positive seven”.

Request Information

Text: “10^3” (says, 10 to the power of 3)

Math ML: <msup><mn>10</mn><span class="fm-script fm-inline"><mn>3</mn>

</span></msup>

HTTP POST XML Request and Reply, 10^3 (says 10 to the power of 3)

POST /api/xml HTTP/1.1

Content-Length: 294

Content-Type: text/plain; charset=UTF-8

Host: api.ispeech.org

Connection: Keep-Alive

Expect: 100-Continue

<data>

<apikey>YOUR_API_KEY_HERE</apikey>

<action>convert</action>

<text>&lt;msup&gt;&lt;mn&gt;10&lt;/mn&gt;&lt;span class=&quot;fm-script fm-inline&quot;&gt;&lt;mn&gt;3&lt;/mn&gt;&lt;/span&gt;&lt;/msup&gt;</text>

<library>libmath</library>

<voice>usenglishfemale</voice>

</data>

HTTP/1.0 200 OK

Connection: close

Access-Control-Allow-Origin: *

Server: iSpeech Cloud/1.2

Accept-Ranges: none

X-Time-Length: 1356

X-Content-Hash: e563c115ba8c4c3e20b57fff4f4bae5e

Content-Length: 8856

Content-Type: audio/mpeg

Cache-Control: no-cache, no-store, must-revalidate, max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

[...mp3 binary data...]

Error codes for Text-to-Speech and General Errors

Code

Summary

1

Invalid API key

2

Could not convert text

3

Not enough credits

4

No action specified

5

Invalid text

6

Too many words

7

Invalid text entry

8

Invalid voice

12

Invalid file format

13

Invalid speed

14

Invalid dictionary

15

Invalid bitrate

16

Invalid frequency

30

Option not enabled for your account. Please contact iSpeech sales at +1 (917) 338-7723 or at sales@ispeech.org to modify your license.

32

Invalid pitch

100

This evaluation account has exceeded its trial period. Please contact iSpeech sales at +1 (917) 338-7723 or at sales@ispeech.org to upgrade your license.

101

Your key has been disabled. Please contact iSpeech sales at +1 (917) 338-7723 or at sales@ispeech.org to modify your license.

997

No api access

998

Unsupported output type

999

Invalid request

1000

Invalid Request Method POST Required

3000

SSML error

Section 3

Automated Speech Recognition

Transaction Types and URL Formats

There are currently three transaction types available for use with the iSpeech API.  All transactions must use the appropriate URL.

TRANSACTION TYPE

INPUT TYPE

URL FORMAT

HTTP GET/POST

URL Encoded

http://api.ispeech.org/api/rest

HTTP GET/POST

XML

http://api.ispeech.org/api/xml

HTTP GET/POST

JSON

http://api.ispeech.org/api/json

Request Parameters

PARAMETER

VALUE

EXAMPLE

Apikey

32 character hex integer

abcdef1234567890abcdef1234567890

Locale

String

en-US

Action

String

recognize

Content-Type

String

audio/x-wav, audio/amr, audio/speex

Audio

String (base64, remove \r\n)

UklGRgAKAQBsl/j2+sa0dR [...]

Output (optional)

String

xml, json, rest (default: rest)

Freeform (optional)

Integer (0 to 7)

3

Model (optional)

String

assistant

Speexmode (optional)

Integer (1 to 3)

1 (speex codec only)

Locales

Standard Locales

Name

Alias

Support

English (United States)

locale=en-US (default)

freeform & command list

English (Canada)

locale=en-CA

freeform & command list

English (United Kingdom)

locale=en-GB

freeform & command list

English (Australia)

locale=en-AU

freeform & command list

Spanish (Spain)

locale=es-ES

freeform & command list

Spanish (Mexico)

locale=es-MX

freeform & command list

Italian (Italy)

locale=it-IT

freeform & command list

French (France)

locale=fr-FR

freeform & command list

French (Canada)

locale=fr-CA

freeform & command list

Polish (Poland)

locale=pl-PL

freeform & command list

Portuguese (Portugal)

locale=pt-PT

freeform & command list

Catalan (Catalan)

locale=ca-ES

command list

Chinese (Taiwan)

locale=zh-TW

command list

Danish (Denmark)

locale=da-DK

command list

German (Germany)

locale=fr-FR

command list

Finnish (Finland)

locale=it-IT

command list

Japanese (Japan)

locale=ja-JP

command list

Korean (Korea)

locale=ko-KR

command list

Dutch (Netherlands)

locale=nl-NL

command list

Norwegian (Norway)

locale=nb-NO

command list

Portuguese (Brazil)

locale=pt-BR

command list

Russian (Russia)

locale=ru-RU

command list

Swedish (Sweden)

locale=sv-SE

command list

Chinese (People's Republic of China)

locale=zh-CN

command list

Chinese (Hong Kong S.A.R.)

locale=zh-HK

command list

Custom Locales

Contact sales@ispeech.org for details.

Speech Recognition Models

Statistical speech recognition models are used to increase the probability of a correct result.  Models with fewer word choices are faster and more accurate than the freeform models.  For example, in the food model the words, “7 up” would be recognized as, “7up”.  Another example is with a food model would recognize the audio from “ice cream”  as “ice cream” instead of “i scream”.

Standard Freeform Models

Name

Value

Use Case

SMS / General Messages

freeform=1

Text Messages

Voice mail

freeform=2

Voice Mail

Dictation

freeform=3

Normal speech

Message (coming soon)

freeform=4

Email

Instant Message (coming soon)

freeform=5

Instant Message

Transcript (coming soon)

freeform=6

Memo (coming soon)

freeform=7

Memorandum

Web (coming soon)

freeform=8

Web search

Standard Non-Freeform Models

Name

Value

Use Case

Assistant

model=assistant

Personal Assistant

Date

model=date

Date

NFL

model=nfl

Football teams

NBA

model=nba

Basketball teams

US Money

model=usmoney

US Money

Numbers to 9

model=numbersto9

Numbers, 0 to 9

Numbers to 99

model=numbersto99

Numbers, 0 to 99

Numbers to 999

model=numbersto999

Numbers, 0 to 999

Time

model=time

Time

Phone number

model=phonenumber

Phone number

Streets

model=streets

Streets

Sports Team

model=sportsteam

Sports Teams

City/State

model=citystate

US City/States

Custom Models

Contact sales@ispeech.org for details.

Speex Modes

The speexmode variable tells the server which format your Speex data is encoded in for improved speech recognition quality. It is highly recommended you include this parameter when using Speex encoding.

Name

Value

Narrowband (8khz)

speexmode=1

Wideband (16khz) - Recommended

speexmode=2

Ultra Wideband (32kz)

speexmode=3

Example Transactions for Freeform Speech

Format of Examples

The following examples are packet captures from TCP connections that used the HTTP protocol.  You can compare your network traffic to these transactions to debug code.  Wireshark can be used to analyze network connections.

HTTP REST transaction for Speech Recognition

HTTP REST Request and Response

POST /api/rest HTTP/1.1

Content-Length: 34875

Content-Type: text/plain; charset=UTF-8

Host: api.ispeech.org

Connection: Keep-Alive

apikey=developerdemokeydeveloperdemokey&action=recognize&freeform=1&content-type=audio/x-wav&output=rest&locale=en-us&audio=[base64 encoded something.wav without \r\n characters]

HTTP/1.0 200 OK

Connection: close

Content-Length: 59

Content-Type: text/plain

Cache-Control: no-cache, no-store, must-revalidate, max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

text=something&confidence=0.0216270890086889&result=success

HTTP JSON transaction for Speech Recognition

HTTP JSON Request and REST Reply

POST /api/json HTTP/1.1

Content-Length: 34897

Content-Type: text/plain; charset=UTF-8

Host: api.ispeech.org

Connection: Keep-Alive

{"apikey":"developerdemokeydeveloperdemokey","action":"recognize",

"freeform":"1", "locale":"en-us", "content-type":"audio/x-wav", "output":"rest", "audio":"[base64 encoded something.wav without \r\n characters]”}

HTTP/1.0 200 OK

Connection: close

Content-Length: 59

Content-Type: application/json

Cache-Control: no-cache, no-store, must-revalidate, max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

text=something&confidence=0.0134419081732631&result=success

HTTP XML network transaction for Speech Recognition

HTTP XML Request and Reply

POST /api/xml HTTP/1.1

Content-Length: 34953

Content-Type: text/plain; charset=UTF-8

Host: api.ispeech.org

Connection: Keep-Alive

User-Agent: Apache-HttpClient/4.0.1 (java 1.5)

Expect: 100-Continue

<data>

<apikey>developerdemokeydeveloperdemokey</apikey>

<action>recognize</action>

<freeform>1</freeform>

<locale>en-us</locale>

<content-type>audio/x-wav</content-type>

<output>xml</output>

<audio>[base64 encoded something.wav without \r\n characters]</audio>

</data>

HTTP/1.0 200 OK

Connection: close

Content-Length: 140

Content-Type: text/xml

Cache-Control: no-cache, no-store, must-revalidate, max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

<?xml version="1.0" encoding="UTF-8"?>

<data>

<text>something</text>

<confidence>0.0216270890086889</confidence>

<result>success</result>

</data>

Command Lists

Command lists are used to limit the possible values returned during speech recognition.  For example, if the command list contains only “yes” and “no”, the result will be either “yes” or “no”.

Example Transactions for Command Lists

Formatting of Examples



The following examples are packet captures of TCP connections that use the HTTP protocol.  You can compare your network traffic with these transactions to debug code.  Wireshark can be used to analyze network connections.  A REST client can be used to make these HTTP requests.

HTTP XML network transaction to detect commands from a list

If a user speaks "say yes", ”say maybe”, or “say no” it will be successfully recognized.

HTTP XML Request and Response

POST /api/xml HTTP/1.1

Content-Length: 80941

Content-Type: text/xml; charset=UTF-8

Host: api.ispeech.org

Expect: 100-Continue

<data>

<apikey>developerdemokeydeveloperdemokey</apikey>

<action>recognize</action>

<locale>en-US</locale>

<output>xml</output>

<alias>command1|YESNOMAYBE</alias>

<YESNOMAYBE>yes|no|maybe</YESNOMAYBE>

<command1>say %YESNOMAYBE%</command1>

<content-type>audio/x-wav</content-type>

<audio>[base64 encoded say_yes.wav without \r\n characters]</audio>

</data>

HTTP/1.0 200 OK

Connection: close

Content-Length: 137

Content-Type: text/xml

Cache-Control: no-cache, no-store, must-revalidate, max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

<?xml version="1.0" encoding="UTF-8"?>

<data>

<text>say yes</text>

<confidence>0.726751327514648</confidence>

<result>success</result>

</data>

HTTP REST network transaction to detect commands from a list

If a user speaks "call john", "call anna", or "call mary" it will be successfully recognized.

HTTP REST Request and Response

POST /api/rest/ HTTP/1.1

Content-Length: 72682

Content-Type: text/plain; charset=UTF-8

Host: api.ispeech.org

Expect: 100-Continue

apikey=developerdemokeydeveloperdemokey&action=recognize&locale=en-us&content-type=audio%2Fwav&output=rest&alias=command1|NAMES

&NAMES=john|mary|anna&command1=call%20%25NAMES%25&audio=[base64 encoded wav without \r\n characters]

HTTP/1.0 200 OK

Connection: close

Content-Length: 58

Content-Type: text/plain

Cache-Control: no-cache, no-store, must-revalidate, max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

text=call+mary&confidence=0.672464966773987&result=success

HTTP POST JSON request to detect commands from a list

If a user speaks "say yes", ”say maybe”, or “say no” it will be successfully recognized.

HTTP POST JSON Request and REST Response

POST /api/json/ HTTP/1.1

Content-Length: 22788

Content-Type: text/plain; charset=UTF-8

Host: api.ispeech.org

Expect: 100-Continue

{"apikey":"developerdemokeydeveloperdemokey","action":"recognize","locale":"en-US","alias":"command1|YESNOMAYBE","YESNOMAYBE":"yes|no|maybe","command1":"say %YESNOMAYBE%","content-type":"audio/x-wav","output":"rest","audio":"[base64 encoded say_yes.wav without \r\n characters]"}

HTTP/1.0 200 OK

Connection: close

Content-Length: 56

Content-Type: application/json

Cache-Control: no-cache, no-store, must-revalidate, max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

text=say+yes&confidence=0.726751327514648&result=success

Advanced Example, HTTP POST XML request to detect multiple audio commands from multiple lists

If a user speaks "set monitor on", ”set monitor off”, or “set dynamite explode”, etc. it will be successfully recognized.

HTTP XML Request and Response

POST /api/xml HTTP/1.1

Content-Length: 91393

Content-Type: text/xml; charset=UTF-8

Host: api.ispeech.org

Connection: Keep-Alive

Expect: 100-Continue

<data>

<apikey>developerdemokeydeveloperdemokey</apikey>

<action>recognize</action>

<locale>en-us</locale>

<content-type>audio/x-wav</content-type>

<output>xml</output>

<alias>command1|command2|MONITORACTIONS|COLORLIST|

DYNAMITEACTIONS|OBJECTLIST</alias>

<MONITORACTIONS>on|off|reset</MONITORACTIONS>

<COLORLIST>blue|green|red|yellow|purple|orange|black|white|cyan</COLORLIST>

<DYNAMITEACTIONS>explode|fizzle out</DYNAMITEACTIONS>

<OBJECTLIST>monitor %MONITORACTIONS%|color %COLORLIST%|dynamite  %DYNAMITEACTIONS%</OBJECTLIST>

<command1>set %OBJECTLIST%</command1>

<command2>quit menu</command2>

<audio>[base64 encoded set_dynamite_explode.wav

without \r\n characters]</audio>

</data>

HTTP/1.0 200 OK

Connection: close

Content-Length: 150

Content-Type: text/xml

Cache-Control: no-cache, no-store, must-revalidate,

max-age=0, proxy-revalidate, no-transform

Pragma: no-cache

<?xml version="1.0" encoding="UTF-8"?><data><text>set dynamite explode</text><confidence>0.589247465133667</confidence>

<result>success</result></data>

Error Codes for Speech Recognition and General Errors

Code

Summary

1

Invalid API key

3

Not enough credits

4

No action specified

12

Invalid file format

14

Invalid dictionary

17

Invalid alias list

18

Alias missing

19

Invalid content type

20

Alias list too complex

21

Could not recognize

23

Invalid locale

24

Bad audio data

25

Model not supported or disabled

26

Selected model does not support desired locale

28

Locale not supported

30

Option not enabled for your account. Please contact iSpeech sales at +1 (917) 338-7723 or at sales@ispeech.org to modify your license.

100

This evaluation account has exceeded its trial period. Please contact iSpeech sales at +1 (917) 338-7723 or at sales@ispeech.org to upgrade your license.

101

Your key has been disabled. Please contact iSpeech sales at +1 (917) 338-7723 or at sales@ispeech.org to modify your license.

997

No api access

998

Unsupported output type

999

Invalid request

1000

Invalid Request Method POST Required

Section 4

Position Markers

Transaction Types and URL Formats

TRANSACTION TYPE

INPUT FORMAT

URL

HTTP GET/POST

URL Encoded

http://api.ispeech.org/api/rest

HTTP GET/POST

XML

http://api.ispeech.org/api/xml

HTTP GET/POST

JSON

http://api.ispeech.org/api/json

Request Parameters

PARAMETER

DATA TYPE

EXAMPLE VALUE

Apikey

32 character hex integer

abcdef1234567890abcdef1234567890

Action

String

markers

Text

String

Hello World

Voice (optional)

String

usenglishfemale (default)

Format (optional)

String

mp3 (default)

Speed (optional)

Integer

-10 to 10 (default: 0)

Startpadding (optional)

Integer (seconds)

5 (default: 0)

Endpadding (optional)

Integer (seconds)

5 (default: 0)

Introduction

Position markers provide information regarding word boundaries to allow applications to visually display the current location in spoken audio.  It is similar to how a karaoke system would display lyrics.

This is accomplished by first retrieving audio from the iSpeech API (see section 2 for more details), then making a second request for an XML document which contains word boundary information.

Example Transactions for Position Markers

Note: Marker data is currently only presented in XML form.

To obtain marker information from the iSpeech API, you query the server in the same manner as a normal text-to-speech request. The only difference between a TTS request and a marker request is the “action” parameter, which is set to “convert” for audio, and “markers” for marker information.


HTTP GET network transaction to retrieve position markers


HTTP GET Request and XML Response

http://api.ispeech.org/api/rest?apikey=YOUR_API_KEY&action=markers
&text=hello+world

<?xml version="1.0" encoding="UTF-8"?>

<markers>

    <text>hello world</text>

    <voice>usenglishfemale</voice>

    <length>894</length>

    <words>2</words>

    <word>

        <start>70</start>

        <end>339</end>

        <index>1</index>

        <length>270</length>

        <text>hello</text>

    </word>

    <word>

        <start>340</start>

        <end>894</end>

        <index>2</index>

        <length>555</length>

        <text>world</text>

    </word>

</markers>

<- Text sent in request

<- Voice parameter sent in request

<- Approximate audio length in ms

<- Amount of words and frames

<- Start offset in milliseconds

<- End offset in milliseconds

<- Index of frame

<- Length of frame

<- Word to highlight



Marker Information Usage Technique

Once you have obtained an audio file and the respective marker information XML document, you are ready to highlight text.

There are many methods to processing iSpeech marker information; the following outlines the most basic of those methods. Use the following steps as a baseline implementation. Implementations will vary greatly depending on the platform.

Media Player Considerations

Your media player must support “location”, “position”, or must notify you of its current progress periodically. For example, in Flash, we set a timer to poll for the audio position every 250 milliseconds. Highlighting will be more accurate with a low interval.

Implementation

If your media player supports retrieval of “current position” or similar, you can follow these basic steps:

1.  Retrieve audio

2.  Retrieve marker information xml

3.  Parse xml into enumerable container/object

4.  Load audio into media player and start playing

5.  Create a timer and set it’s interval to 250 milliseconds

6.  Inside of the newly created timer, at every interval query the media player’s current position

7.  Convert the position to milliseconds (if you have number such as 1.343, simply multiply by 1000)

8.  Move to first (or next) “word” node inside of marker information xml document

9.  Check to see if current position is greater than or equal to the value of ”start” AND ALSO current position is less than or equal to the value of “end”, highlight the specified “text”

10.  If current position is greater than “word” “end” value go to step 8

You can follow the above steps until the audio file is exhausted.

Notes


Due to the overhead of creation, we strongly recommend using short sentences instead of large blocks of text when requesting marker information.

The same parameters must be sent in the markers request as the original TTS audio request. For example, if you pass a “speed” parameter during audio conversion, you must also send this parameter in your marker information request. If you fail to do so, the marker information will not line up correctly.

File type affects audio length. A MP3 file is always longer than a WAV file due to compression padding. The API will modify the file length accordingly.

Error codes for Position Markers and General Errors

Code

Summary

1

Invalid API key

2

Could not convert text

3

Not enough credits

4

No action specified

5

Invalid text

6

Too many words

7

Invalid text entry

8

Invalid voice

12

Invalid file format

13

Invalid speed

14

Invalid dictionary

15

Invalid bitrate

16

Invalid frequency

30

Option not enabled for your account. Please contact iSpeech sales at +1 (917) 338-7723 or at sales@ispeech.org to modify your license.

33

Invalid text or markers not supported for the selected voice

34

Markers do not support audio padding or other option.

100

This evaluation account has exceeded its trial period. Please contact iSpeech sales at +1 (917) 338-7723 or at sales@ispeech.org to upgrade your license.

101

Your key has been disabled. Please contact iSpeech sales at +1 (917) 338-7723 or at sales@ispeech.org to modify your license.

997

No api access

998

Unsupported output type

999

Invalid request

1000

Invalid Request Method POST Required

Section 5

Visemes

Transaction Types and URL Formats

TRANSACTION TYPE

INPUT FORMAT

URL

HTTP GET/POST

URL Encoded

http://api.ispeech.org/api/rest

HTTP GET/POST

XML

http://api.ispeech.org/api/xml

HTTP GET/POST

JSON

http://api.ispeech.org/api/json

Request Parameters

PARAMETER

DATA TYPE

EXAMPLE VALUE

Apikey

32 character hex integer

abcdef1234567890abcdef1234567890

Action

String

viseme

Text

String

Hello World

Voice (optional)

String

usenglishfemale (default)

Format  (optional)

String

mp3 (default)

Speed (optional)

Integer

-10 to 10 (default: 0)

Startpadding (optional)

Integer (seconds)

5 (default: 0)

Endpadding (optional)

Integer (seconds)

5 (default: 0)

Introduction

Visemes provide information regarding the mouth position and time interval of spoken audio which allows applications to visually pronounce audio.

This is accomplished by first retrieving audio from the iSpeech API (see section 2 for more details), then making a second request for an XML document which contains viseme information.

Example Transaction for Viseme Retrieval

Note: Viseme data is currently only presented in XML form.

To obtain viseme information from the iSpeech API, you query the server in the same manner as a normal text-to-speech request. The only difference between a TTS request and a marker request is the “action” parameter, which is set to “convert” for audio, and “viseme” for viseme information.

HTTP GET network transaction to retrieve viseme positions

HTTP GET Request and XML Response

http://api.ispeech.org/api/rest?apikey=YOUR_API_KEY&action=viseme
&text=hello+world

<visemes>

   <text>hello world</text>

   <voice>usenglishfemale</voice>

   <length>753</length>

   <frames>9</frames>

   <viseme>

      <start>1</start>

      <end>74</end>

      <index>1</index>

      <length>74</length>

      <mouth>12</mouth>

   </viseme>

   <viseme>

      <start>75</start>

      <end>102</end>

      <index>2</index>

      <length>28</length>

      <mouth>4</mouth>

   </viseme>

   <viseme>

      <start>103</start>

      <end>182</end>

      <index>3</index>

      <length>80</length>

      <mouth>14</mouth>

   </viseme>

   <viseme>

      <start>183</start>

      <end>269</end>

      <index>4</index>

      <length>87</length>

      <mouth>8</mouth>

   </viseme>

   <viseme>

      <start>270</start>

      <end>359</end>

      <index>5</index>

      <length>90</length>

      <mouth>7</mouth>

   </viseme>

   <viseme>

      <start>360</start>

      <end>470</end>

      <index>6</index>

      <length>111</length>

      <mouth>5</mouth>

   </viseme>

   <viseme>

      <start>471</start>

      <end>660</end>

      <index>7</index>

      <length>190</length>

      <mouth>14</mouth>

   </viseme>

   <viseme>

      <start>661</start>

      <end>752</end>

      <index>8</index>

      <length>92</length>

      <mouth>19</mouth>

   </viseme>

   <viseme>

      <start>753</start>

      <end>753</end>

      <index>9</index>

      <length>1</length>

      <mouth>0</mouth>

   </viseme>

</visemes>

<- Text sent in request

<- Voice parameter sent in request

<- Approximate audio length in ms

<- Amount of frames

<- Start offset in milliseconds

<- End offset in milliseconds

<- Index of frame

<- Length of frame

<- Mouth position (0-21 maps to the 1-22 standard)


Viseme Chart

Mouth 0

 Mouth 1

Mouth 2

Mouth 3

Mouth 4

Mouth 5

Mouth 6

 Mouth 7

Mouth 8

Mouth 9

Mouth 10

Mouth 11

 Mouth 12

Mouth 13

Mouth 14

Mouth 15

Mouth 16

 Mouth 17

Mouth18

 Mouth 19

Mouth 20

Mouth 21


Viseme Usage Technique

Once you have obtained an audio file and the respective viseme information XML document, you are ready to animate mouth positions to simulate speaking.

There are many methods to processing iSpeech viseme information; the following outlines the most basic of those methods. Use the following steps as a baseline implementation. Implementations will vary greatly depending on the platform.

Media Player Considerations

Your media player must support “location”, “position”, or must notify you of its current progress periodically. For example, in Flash, we set a timer to poll for the audio position every 250 milliseconds. Mouth positioning will be more accurate with a low interval.

Implementation

If your media player supports retrieval of “current position” or similar, you can follow these basic steps:

1.  Retrieve audio

2.  Retrieve viseme information xml

3.  Parse xml into enumerable container/object

4.  Load audio into media player and start playing

5.  Create a timer and set it’s interval to 250 milliseconds

6.  Inside of the newly created timer, at every interval query the media player’s current position

7.  Convert the position to milliseconds (if you have number such as 1.343, simply multiply by 1000)

8.  Move to first (or next) “word” node inside of marker information xml document

9.  Check to see if current position is greater than or equal to the value of ”start” AND ALSO current position is less than or equal to the value of “end”, highlight the specified “text”

10.  If current position is greater than “word” “end” value go to step 8

You can follow the above steps until the audio file is exhausted.

Notes


Due to the overhead of creation, we strongly recommend using short sentences instead of large blocks of text when requesting viseme information.

The same parameters must be sent in the viseme request as the original TTS audio request. For example, if you pass a “speed” parameter during audio conversion, you must also send this parameter in your marker information request. If you fail to do so, the viseme will not line up correctly.

File type affects audio length. A MP3 file is always longer than a WAV file due to compression padding. The API will modify the file length accordingly.

Error codes for Visemes and General Errors

Code

Summary

1

Invalid API key

2

Could not convert text

3

Not enough credits

4

No action specified

5

Invalid text

6

Too many words

7

Invalid text entry

8

Invalid voice

12

Invalid file format

13

Invalid speed

14

Invalid dictionary

15

Invalid bitrate

16

Invalid frequency

29

Viseme not supported for the selected voice.

30

Option not enabled for your account. Please contact iSpeech sales at +1 (917) 338-7723 or at sales@ispeech.org to modify your license.

32

Invalid pitch

100

This evaluation account has exceeded its trial period. Please contact iSpeech sales at +1 (917) 338-7723 or at sales@ispeech.org to upgrade your license.

101

Your key has been disabled. Please contact iSpeech sales at +1 (917) 338-7723 or at sales@ispeech.org to modify your license.

997

No api access

998

Unsupported output type

999

Invalid request

1000

Invalid Request Method POST Required

iSpeech API Specification Version 2.0
The iSpeech API allows developers to implement Text-To-Speech (TTS) and Automated Voice Recognition (ASR) in any Internet enabled application.

The API's are platform agnostic which means any device that can record or play audio and is connected to the Internet can use the iSpeech API.
General Working Notes

The API accepts standard HTTP requests in XML, JSON or URL-encoded formats for easy integration in your favorite development language.

Every request must have a valid API key. To obtain an API key please visit our sign up page.

All requests must be sent to:

The root node for XML requests is "data".

All API calls are synchronous.

HTTP POST must be used for XML or JSON requests, GET request will fail with an error code.

An action must be specified with every request.

The API may be accessed via HTTP or HTTPS (SSL) connections.

You can make a request in XML and receive a response in JSON or URL encoding by specifying the output parameter to JSON, XML, or REST.

Text-To-Speech API

The iSpeech Text-To-Speech API allows you to create high quality speech audio in multiple formats, including mp3, wav, wma, mp4, ogg, flac. The iSpeech API is fast enough to not require call-back URL's. This means you'll always receive audio data or an error message in the same request.

Since the Text-To-Speech API is so easy to use, we provide this very simple one-line quick start. Simply change the API key in the URL to your API key, and you'll receive an mp3 containing the text you specified: http://api.ispeech.org/api/rest?apikey=YOURAPIKEYHERE&action=convert&text=Your+url+encoded+text

Actions

All actions return a result value with either success or error. If the result value is error and appropriate error code and message will be returned in the request. Also, a "202 Accepted" response will be issued along with the error result.

The following actions are available for the text to speech API.

Information

Required Parameters:

Optional Parameters:

Response Values:

Example Response:

Convert

Required Parameters:

Optional Parameters:

Response Values:

Returns a HTTP "200 OK" containing the binary audio data on success. If you receive a "202 Accepted", parse the response for an error message.

Speech Recognition API

The iSpeech Automated Speech Recognition API allows you to specify simple word list based grammars or freeform dictation.

Due to the complexity of the Speech Recognition API, we highly recommend using the appropriate language SDK instead of writing your own custom implementation.

Note: You must specify the audio content type in your request. URL encoded requests must past only audio data in their POST. Your requested URL must contain your API key and any other parameters.

The following actions are available for the text to speech API.

Recognize

Required Parameters:

Required Grammar/Commands Parameters:

Response Values:

Example Response:

result=success&text=say+yes&confidence=0.89235

Error Codes

If something goes wrong, you'll receive an error message along with an error code, below is a chart containing the possible error codes.

Example error response:

result=error&code=1&message=Invalid+api+key
Contact    Investors    Policies© 2009-2014 iSpeech, Inc. All Rights Reserved. iSpeech and the iSpeech logo are registered trademarks of iSpeech, Inc.
